FEATURES
Interior Exterior Height
(m)		 Water volume
(m3)		 Water depth (m) Liner
75/100		 Filtration Weight
(kg)
Width
(m)		 Length
(m)		 Width
(m)		 Length
(m)
2.90 4.31 3.24 4.67 1.28 13.76 1.10 Solid color Cartridge 12 m3/h 2 130  (2 paletes)
STANDARD KIT
STRUCTURE:
  • Base structure with steel panels
  • Beams
  • Pillars
  • Ledge/rim in reinforced concrete that looks like natural-wood, dyed in the concrete
  • Inner wall reinforcement of 0,4mm metal sheet
FILTRATION (CARTRIDGE):
  • 12 m3/h Skimfiltre
  • 3/4 CV Pump
  • ABS outlet nozzle
LINER 75/100:
  • Solid colour liner 75/100
  • HUNG fixation profile
  • Locked profile
  • Special felt carpet 350gr.
    .
OPTIONALS:
  • Cleaning kit;
  • Interior stainless steel ladder;
  • Exterior stainless steel ladder;
  • Mini plumbing kit, including valves, accessories e pipe for pump located up to 5m away from swimming pool;
  • Nuts and bolts set;
  • Installation manual.

SKIMFILTRE

The SKIMFILTER is manufactured in ABS with anti-UV treatment, plastic material perfectly adaptable to the swimming pool ambiance.

LINER 75/100

The liner is a PVC membrane that ensures the swimming pool’s waterproof. 100% high elasticity virgin vinyl, with anti-UV and anti-algae treatment.

PUMP

0,75 CV Pump,
0,85 Kw absorbed power,
230V tension, 50Hz Frequency

STAINLESS STEEL LADDERS

FEATURES
Interior Exterior Height
(m)		 Water volume
(m3)		 Water depth  (m) Liner
75/100		 Filtration Weight
(kg)
Width
(m)		 Length
(m)		 Width
(m)		 Length
(m)
2.90 4.31 3.24 4.67 1.40 15.32 1.22 Solid color Cartridge 12 m3/h 2 160  (2 paletes)
STANDARD KIT
STRUCTURE:
  • Base structure with steel panels
  • Beams
  • Pillars
  • Ledge/rim in reinforced concrete that looks like natural-wood, dyed in the concrete
  • Inner wall reinforcement of 0,4mm metal sheet
FILTRATION (CARTRIDGE):
  • 12 m3/h Skimfiltre
  • 3/4 CV Pump
  • ABS outlet nozzle
LINER 75/100:
  • Solid color liner 75/100
  • HUNG fixation profile
  • Locked profile
  • Special felt carpet 350gr.
    .
OPTIONALS:
  • Cleaning kit;
  • Interior stainless steel ladder;
  • Exterior stainless stell ladder;
  • Mini plumbing kit, including valves, accessories e pipe for pump located up to 5m away from swimming pool;
  • Nuts and bolts set;
  • Installation manual.

SKIMFILTRE

The SKIMFILTER is manufactured in ABS with anti-UV treatment, plastic material perfectly adaptable to the swimming pool ambiance.

LINER 75/100

The liner is a PVC membrane that ensures the swimming pool’s waterproof. 100% high elasticity virgin vinyl, with anti-UV and anti-algae treatment.

PUMP

0,75 CV Pump,
0,85 Kw absorbed power,
230V tension, 50Hz Frequency.

STAINLESS STEEL LADDERS

OPTIONALS
filtro_areia
SAND FILTER

Being the most widely used filtration system, we have combined sand filter quality with the effectiveness of a Jacuzzi pump in a single equipment.



cobertura_inverno
WINTER COVER

Essential for proper swimming pool hibernation, the winter cover is recommended to protect the swimming pool from leaves and debris.

quadro_prg
CONTROL PANEL

The control panel has been designed to control de swimming pool filtration in an efficient and leisurely fashion.



cobertura_verao
SUMMER COVER

Also known as isothermal cover, its main function is to preserve the water temperature.



iluminacao_leds
LED PROJECTORS

The lighting LED kit contains a special beam, a filtration electrical control panel with 220/12v differential, a through a pipe and a LED spotlight.
